LM317MDT
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Obsolete Positive GULL WING Not Qualified Linear Voltage Regulator IC 0C~125C TJ 500mA 6.5mm 3V
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.6864
≥1 USD $0.6864
≥10 USD $0.6028
≥100 USD $0.566368
≥500 USD $0.462352
≥1000 USD $0.42944
≥3000 USD $0.365482
Inventory: 416
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Surface Mount YES
Technical
Operating Temperature 0°C~125°C TJ
Packaging Tube
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Other Regulators
Technology BIPOLAR
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 2.25mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LM317
Pin Count 3
JESD-30 Code R-PSSO-G2
Number of Outputs 1
Qualification Status Not Qualified
Voltage - Input (Max) 40V
Output Type Adjustable
Output Configuration Positive
Current - Output 500mA
Voltage - Output (Min/Fixed) 1.2V
Number of Regulators 1
Protection Features Over Temperature, Short Circuit
PSRR 80dB ~ 65dB (120Hz)
Dropout Voltage1-Nom 3V
Voltage - Output (Max) 37V
Load Regulation-Max(%) 5.8%
Input-Output Voltage Differential-Max 40V
Input-Output Voltage Differential-Min 3V
Dimensions
Height Seated (Max) 2.63mm
Length 6.5mm
Compliance
RoHS Status ROHS3 Compliant
