LK115D33
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LK115 Tube Surface Mount Over Current Over Temperature voltage regulator linear 170mV 4.9mm 100mA -40C~125C
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.218274
≥1 USD $0.218274
≥10 USD $0.205919
≥100 USD $0.194266
≥500 USD $0.18327
≥1000 USD $0.172899
Inventory: 1168
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Input Bias Current 1.5mA
Input Voltage Absolute-Max 20V
Min Current Limit 120mA
Voltage Tolerance-Max 5%
Dropout Voltage1-Nom 0.17V
Dropout Voltage 170mV
PSRR 79dB ~ 57dB (120Hz ~ 10kHz)
Voltage Dropout (Max) 0.17V @ 60mA Typ
Current - Quiescent (Iq) 500μA
Protection Features Over Current, Over Temperature
Min Input Voltage 4.3V
Number of Regulators 1
Output Voltage 1 3.3V
Control Features Enable
Current - Output 100mA
Output Configuration Positive
Output Type Fixed
Output Voltage 3.3V
Voltage - Input (Max) 20V
Qualification Status Not Qualified
Number of Outputs 1
Current - Supply (Max) 3mA
Pin Count 8
Base Part Number LK115
Time@Peak Reflow Temperature-Max (s) 30
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
