LK112M17TR
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LK112 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 700mV 2.9mm 250muA -30C~125C
PDF
/
Buying Options
Total Price: USD $2.64
Unit Price: USD $2.6391
≥1 USD $2.6391
≥10 USD $2.166
≥100 USD $2.09855
≥500 USD $2.03015
≥1000 USD $1.9627
Inventory: 59302
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Number of Pins 5
Technical
Operating Temperature -30°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Tin (Sn)
Subcategory Other Regulators
Packing Method TAPE AND REEL
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LK112
Pin Count 5
Number of Outputs 1
Qualification Status Not Qualified
Voltage - Input (Max) 14V
Output Voltage 1.7V
Output Type Fixed
Output Configuration Positive
Control Features Enable
Output Voltage 1 1.7V
Number of Regulators 1
Min Input Voltage 2.5V
Protection Features Over Current, Over Temperature
Current - Quiescent (Iq) 250μA
PSRR 55dB (400Hz)
Dropout Voltage 700mV
Dropout Voltage1-Nom 0.17V
Min Current Limit 150mA
Input Bias Current 175μA
Dimensions
Length 2.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
