L7815CD2T-TR

STMicroelectronics
RoHS
RoHS RoHS compliant
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description L7815 Tape & Reel (TR) Surface Mount Over Temperature Short Circuit voltage regulator linear 2V 4.6mm 1.5A 0C~125C
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.9152
≥1 USD $0.9152
≥10 USD $0.82016
≥100 USD $0.778272
≥500 USD $0.639408
≥1000 USD $0.597731
≥3000 USD $0.528229
Inventory: 1480
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Width 9.35mm
Length 10.4mm
Height 4.6mm

Technical

Nominal Output Voltage 15V
Voltage Tolerance-Max 4%
Power Supply Rejection Ratio (PSRR) 54dB
Min Output Voltage 15V
Dropout Voltage1-Nom 2V
Dropout Voltage 2V
PSRR 54dB (120Hz)
Voltage Dropout (Max) 2V @ 1A Typ
Protection Features Over Temperature, Short Circuit
Min Input Voltage 17V
Number of Regulators 1
Output Voltage 1 15V
Quiescent Current 8mA
Output Configuration Positive
Max Output Current 1.5A
Output Type Fixed
Output Voltage 15V
Voltage - Input (Max) 35V
Number of Outputs 1
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number L7815
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position SINGLE
Technology BIPOLAR
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature 0°C~125°C

Physical

Weight 4.535924g
Number of Pins 3
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 8 Weeks
