LT1123CST#PBF
RoHS
RoHS compliant
RoHS compliantPackage TO-261-4, TO-261AA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear Regulator Controllers
Description
Tube LT1123 PRODUCTION (Last Updated: 2weeks ago) BIPOLAR linear regulator controller 4A 0C~125C 6.505mm 3V
PDF
/
Buying Options
Total Price: USD $5.39
Unit Price: USD $5.3944
≥1 USD $5.3944
≥10 USD $4.8444
≥100 USD $4.579494
≥500 USD $3.968914
≥1000 USD $3.765414
≥3000 USD $3.378681
Inventory: 475
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 6.505mm
Technical
Output Voltage Accuracy 1 %
Dropout Voltage 300mV
Max Input Voltage 20V
Min Input Voltage 3V
Output Voltage 1 5V
Max Output Voltage 5V
Output Current 4A
Operating Supply Current 700μA
Polarity Positive
Max Output Current 4A
Output Voltage 5V
Number of Outputs 1
JESD-30 Code R-PDSO-G4
Pin Count 3
Base Part Number LT1123
Time@Peak Reflow Temperature-Max (s) 30
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Terminal Finish Matte Tin (Sn)
Type Positive Fixed
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2005
Packaging Tube
Operating Temperature 0°C~125°C
Physical
Number of Pins 3
Package / Case TO-261-4, TO-261AA
Mount Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 8 Weeks
