MIC5321-KDYMT-TR
RoHS
RoHS compliant
RoHS compliantPackage 6-UFDFN Exposed Pad, 6-TMLF?
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
MIC5321 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 35mV 0.5mm 150mA 150mA -40C~125C
PDF
/
Buying Options
Total Price: USD $0.99
Unit Price: USD $0.988614
≥1 USD $0.988614
≥200 USD $0.383367
≥500 USD $0.370238
≥1000 USD $0.363673
Inventory: 1650
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-UFDFN Exposed Pad, 6-TMLF?
Number of Pins 6
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2008
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Technology CMOS
Terminal Position DUAL
Terminal Form NO LEAD
Number of Functions 1
Terminal Pitch 0.5mm
Base Part Number MIC5321
Number of Outputs 2
Voltage - Input (Max) 5.5V
Output Voltage 1.85V
Output Type Fixed
Output Configuration Positive
Current - Output 150mA 150mA
Control Features Enable
Output Voltage 1 2.6V
Voltage - Output (Min/Fixed) 1.85V 2.6V
Number of Regulators 2
Protection Features Over Current, Over Temperature
Current - Quiescent (Iq) 190μA
Voltage Dropout (Max) 0.1V @ 150mA 0.1V @ 150mA
PSRR 75dB ~ 45dB (1kHz ~ 20kHz)
Dropout Voltage 35mV
Min Current Limit 300mA
Output Voltage 2 1.85V
Compliance
RoHS Status ROHS3 Compliant
