MIC5320-MFYML-TR
RoHS
RoHS compliant
RoHS compliantPackage 6-WFDFN Exposed Pad, 6-MLF?
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
MIC5320 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 35mV 150mA 150mA -40C~125C
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.4028
≥1 USD $0.4028
≥10 USD $0.3306
≥100 USD $0.32015
≥500 USD $0.31065
≥1000 USD $0.3002
Inventory: 1230
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Min Current Limit 300mA
Dropout Voltage 35mV
PSRR 65dB ~ 45dB (1kHz ~ 20kHz)
Voltage Dropout (Max) 0.1V @ 150mA 0.1V @ 150mA
Current - Quiescent (Iq) 120μA
Protection Features Over Current, Over Temperature
Number of Regulators 2
Voltage - Output (Min/Fixed) 1.5V 2.8V
Control Features Enable
Current - Output 150mA 150mA
Output Configuration Positive
Output Type Fixed
Output Voltage 1.5V
Voltage - Input (Max) 5.5V
Current - Supply (Max) 190μA
Base Part Number MIC5320
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Supplier Device Package 6-MLF? (1.6x1.6)
Number of Pins 6
Package / Case 6-WFDFN Exposed Pad, 6-MLF?
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
