MIC5310-LLYML-TR
RoHS
RoHS compliant
RoHS compliantPackage 8-VFDFN Exposed Pad, 8-MLF?
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
MIC5310 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 35mV 150mA 150mA -40C~125C
PDF
/
Buying Options
Total Price: USD $9.14
Unit Price: USD $9.137764
≥1 USD $9.137764
≥10 USD $8.620533
≥100 USD $8.13258
≥500 USD $7.672242
≥1000 USD $7.237967
Inventory: 1475
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-VFDFN Exposed Pad, 8-MLF?
Number of Pins 8
Supplier Device Package 8-MLF? (2x2)
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2011
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Base Part Number MIC5310
Current - Supply (Max) 190μA
Voltage - Input (Max) 5.5V
Output Voltage 2.7V
Output Type Fixed
Output Configuration Positive
Current - Output 150mA 150mA
Control Features Enable
Voltage - Output (Min/Fixed) 2.7V 2.7V
Number of Regulators 2
Protection Features Over Current, Over Temperature
Current - Quiescent (Iq) 120μA
Voltage Dropout (Max) 0.1V @ 150mA 0.1V @ 150mA
PSRR 70dB ~ 65dB (1kHz ~ 20kHz)
Dropout Voltage 35mV
Min Current Limit 300mA
Compliance
RoHS Status ROHS3 Compliant
