MIC5295YD-TR

Microchip Technology
RoHS
RoHS RoHS compliant
Package TO-252-6, DPak (5 Leads + Tab)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description MIC5295 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity voltage regulator linear 300mV 150mA -40C~125C
PDF
/
Buying Options
Total Price: USD $0.96
Unit Price: USD $0.9592
≥1 USD $0.9592
≥10 USD $0.7832
≥100 USD $0.759
Inventory: 1296
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Technical

Dropout Voltage 300mV
PSRR 50dB (1kHz)
Voltage Dropout (Max) 0.5V @ 150mA
Current - Quiescent (Iq) 35μA
Protection Features Over Current, Over Temperature, Reverse Polarity
Min Input Voltage 2.3V
Number of Regulators 1
Voltage - Output (Min/Fixed) 1.24V
Control Features Enable
Output Configuration Positive
Max Output Current 150mA
Output Type Adjustable
Output Voltage 20V
Voltage - Input (Max) 24V
Current - Supply (Max) 4mA
JESD-30 Code R-PSSO-G5
Base Part Number MIC5295
Number of Functions 1
Terminal Form GULL WING
Terminal Position SINGLE
Number of Terminations 5
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Number of Pins 6
Package / Case TO-252-6, DPak (5 Leads + Tab)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 10 Weeks
