S-817A31APF-CUUTFG

ABLIC U.S.A. Inc.
RoHS
RoHS RoHS compliant
Package 4-SMD, Flat Leads
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description Tape & Reel (TR) Surface Mount Short Circuit RoHS Compliant voltage regulator linear 3.1V 0.5mm 50mA -40C~85C TA
PDF
/
Inventory: 6738
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Surface Mount
Package / Case 4-SMD, Flat Leads
Surface Mount YES

Technical

Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series S-817
JESD-609 Code e6
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Terminal Finish Tin/Bismuth (Sn/Bi)
Technology CMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.65mm
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) 10
Pin Count 4
JESD-30 Code R-PDSO-F4
Qualification Status Not Qualified
Voltage - Input (Max) 10V
Output Type Fixed
Output Configuration Positive
Current - Output 50mA
Output Voltage 1 3.1V
Voltage - Output (Min/Fixed) 3.1V
Number of Regulators 1
Protection Features Short Circuit
Current - Quiescent (Iq) 2.5μA
Voltage Dropout (Max) 0.41V @ 10mA
Output Voltage1-Min 3.038V

Dimensions

Height Seated (Max) 0.5mm

Compliance

RoHS Status RoHS Compliant
