TPS62410DRCTG4
RoHS
RoHS compliant
RoHS compliantPackage 10-VFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
TPS62410 Tape & Reel (TR) Nickel/Palladium/Gold (Ni/Pd/Au) Active DC to DC switching regulator 3.6V 3mm 800mA 2.25MHz
PDF
/
Buying Options
Total Price: USD $0.73
Unit Price: USD $0.727491
≥1 USD $0.727491
≥10 USD $0.686314
≥100 USD $0.647474
≥500 USD $0.610814
≥1000 USD $0.576235
Inventory: 1128
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Height 900μm
Technical
Switcher Configuration PHASE-SHIFT
Min Output Voltage 600mV
Synchronous Rectifier Yes
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 2.25MHz
Control Mode VOLTAGE-MODE
Topology Buck
Voltage - Output (Min/Fixed) 0.6V
Max Output Voltage 6V
Quiescent Current 32μA
Output Configuration Positive
Analog IC - Other Type DUAL SWITCHING CONTROLLER
Input Voltage-Nom 3.6V
Voltage - Input (Min) 2.5V
Operating Supply Voltage 6V
Max Output Current 800mA
Output Type Adjustable
Output Voltage 6V
Efficiency 95 %
Number of Outputs 2
Function Step-Down
Base Part Number TPS62410
Terminal Pitch 0.5mm
Supply Voltage 3.6V
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Subcategory Switching Regulator or Controllers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 26.109911mg
Number of Pins 10
Surface Mount YES
Package / Case 10-VFDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
