BD90640HFP-CTR
RoHS
RoHS compliant
RoHS compliantPackage TO-263-8, D2Pak (7 Leads + Tab), TO-263CA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
Cut Tape (CT) Active Step-Down SWITCHING REGULATOR DC to DC switching regulator 13.2V 8mm 4A 50kHz~500kHz
PDF
/
Buying Options
Total Price: USD $2.57
Unit Price: USD $2.5696
≥1 USD $2.5696
≥10 USD $2.31088
≥100 USD $2.179936
≥500 USD $1.857152
≥1000 USD $1.743808
≥3000 USD $1.52585
Inventory: 1224
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 8mm
Length 9.395mm
Height Seated (Max) 2.005mm
Technical
Synchronous Rectifier No
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 50kHz~500kHz
Control Mode CURRENT-MODE
Topology Buck
Voltage - Output (Min/Fixed) 0.8V
Current - Output 4A
Output Configuration Positive
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 13.2V
Voltage - Input (Min) 5V
Output Type Adjustable
Output Voltage 36V
Number of Outputs 1
Function Step-Down
JESD-30 Code R-PSSO-G7
Terminal Form GULL WING
Terminal Position SINGLE
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q100
Published 2015
Packaging Cut Tape (CT)
Operating Temperature -40°C~125°C TA
Physical
Surface Mount YES
Package / Case TO-263-8, D2Pak (7 Leads + Tab), TO-263CA
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
