TC1121CUA713
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
TC1121 Tape & Reel (TR) Matte Tin (Sn) Obsolete DC to DC switching regulator 5V 3mm 100mA 333mW
PDF
/
Inventory: 2009
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Technical
Switcher Configuration DOUBLER INVERTER
Synchronous Rectifier No
Frequency - Switching 10kHz~200kHz
Logic Function Inverting
Topology Charge Pump
Voltage - Output (Min/Fixed) -Vin
Output Power 333mW
Current - Output 100mA
Output Configuration Negative
Analog IC - Other Type SWITCHED CAPACITOR CONVERTER
Min Supply Voltage 2.4V
Max Supply Voltage 5.5V
Input Voltage-Nom 5V
Voltage - Input (Min) 2.4V
Output Type Fixed
Output Voltage -5.5V
Number of Outputs 1
Function Ratiometric
Base Part Number TC1121
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Other Analog ICs
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
