UCC3807D-3
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
UCC3807 Buck Boost Flyback Forward Converter SEPIC Tube e4 DC to DC switching controller 20ns 100mA 72.603129mg 400mV
PDF
/
Buying Options
Total Price: USD $3.27
Unit Price: USD $3.26705
≥1 USD $3.26705
≥10 USD $2.6809
≥100 USD $2.5973
≥500 USD $2.51275
≥1000 USD $2.42915
Inventory: 52991
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
Technical
Max Duty Cycle 78 %
Switcher Configuration BUCK-BOOST
Fall Time (Typ) 20 ns
Synchronous Rectifier No
Rise Time 20 ns
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 202kHz
Control Mode CURRENT-MODE
Topology Buck, Boost, Flyback, Forward Converter, SEPIC
Input Voltage (Min) 4.3V
Quiescent Current 1.3mA
Voltage - Supply (Vcc/Vdd) 4.1V~13.5V
Output Current 100mA
Output Configuration Positive
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 10V
Output Type Transistor Driver
Output Voltage 400mV
Number of Outputs 1
Function Step-Up, Step-Down, Step-Up/Step-Down
Base Part Number UCC3807
Frequency 1MHz
Supply Voltage 10V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Switching Regulator or Controllers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Weight 72.603129mg
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
