UC3825DWTR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
UC3825 Buck Boost Flyback Forward Converter Full-Bridge Half-Bridge Push-Pull Tape & Reel (TR) e4 DC to DC switching controller 30ns 200mA 473.692182mg 13V
PDF
/
Buying Options
Total Price: USD $4.22
Unit Price: USD $4.224
≥1 USD $4.224
≥10 USD $3.7928
≥100 USD $3.585472
≥500 USD $3.107544
≥1000 USD $2.948211
≥3000 USD $2.645403
Inventory: 1094
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 10.3mm
Height 2.65mm
Technical
Output Phases 1
Max Duty Cycle 85 %
Fall Time (Typ) 30 ns
Synchronous Rectifier No
Supply Current-Max (Isup) 33mA
Rise Time 30ns
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 30V
Frequency - Switching 340kHz~460kHz
Control Mode VOLTAGE-MODE
Topology Buck, Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull
Input Voltage (Min) 8.8V
Control Features Current Limit, Enable, Frequency Control, Ramp, Soft Start
Voltage - Supply (Vcc/Vdd) 8.4V~30V
Output Current 200mA
Output Configuration Positive
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 15V
Output Type Transistor Driver
Output Voltage 13V
Number of Outputs 2
Function Step-Up, Step-Down, Step-Up/Step-Down
Base Part Number UC3825
Frequency 1MHz
Supply Voltage 15V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Switching Regulator or Controllers
Additional Feature CAN ALSO BE CONFIGURED IN CURRENT MODE
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA
Physical
Weight 473.692182mg
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
