UC2842AN
RoHS
/
Package 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
CURRENT-MODE BIPOLAR DUAL Through Hole DC-DC Controller IC -25C~85C TA Up to 500kHz 30V 9.78mm
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8303
≥1 USD $0.8303
≥10 USD $0.68115
≥100 USD $0.66025
≥500 USD $0.6384
≥1000 USD $0.6175
Inventory: 8711
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Surface Mount NO
Technical
Operating Temperature -25°C~85°C TA
Packaging Tube
Published 2005
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Switching Regulator or Controllers
Technology BIPOLAR
Terminal Position DUAL
Terminal Pitch 2.54mm
Frequency 60kHz
Base Part Number UC284*A
JESD-30 Code R-PDIP-T8
Function Step-Up, Step-Up/Step-Down
Number of Outputs 1
Output Type Transistor Driver
Input Voltage-Nom 15V
Analog IC - Other Type SWITCHING CONTROLLER
Output Configuration Positive
Voltage - Supply (Vcc/Vdd) 10V~30V
Control Features Frequency Control
Topology Boost, Flyback
Control Mode CURRENT-MODE
Output Current-Max 1A
Frequency - Switching Up to 500kHz
Input Voltage (Max) 30V
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier No
Switcher Configuration SINGLE
Duty Cycle (Max) 96%
Dimensions
Height Seated (Max) 4.45mm
Length 9.78mm
Width 7.62mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
