ISL6431CB
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
VOLTAGE-MODE DUAL RoHS Compliant PUSH-PULL DC-DC Controller IC 70C 300kHz 5V 4.9mm
PDF
/
Buying Options
Total Price: USD $1.38
Unit Price: USD $1.3816
≥1 USD $1.3816
≥10 USD $1.18184
≥100 USD $1.107744
≥500 USD $1.000208
≥1000 USD $0.975357
Inventory: 919
Minimum: 1
-
+
Technical Details
Physical
Package / Case SOIC
Surface Mount YES
Number of Pins 8
Technical
Published 2001
JESD-609 Code e0
Moisture Sensitivity Level (MSL) 1
Number of Terminations 8
ECCN Code EAR99
Terminal Finish TIN LEAD
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Frequency 340kHz
Pin Count 8
Operating Supply Voltage 5V
Input Voltage-Nom 5V
Temperature Grade COMMERCIAL
Analog IC - Other Type SWITCHING CONTROLLER
Output Configuration Positive
Current - Output 20A
Frequency (Max) 340kHz
Voltage - Output 3.3V
Control Mode VOLTAGE-MODE
Frequency - Switching 300kHz
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier Yes
Switcher Configuration PUSH-PULL
Max Duty Cycle 100 %
Duty Cycle (Max) 100 %
Clock Sync No
Number of Output Phases 1
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
