MAX6191BESA
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Surface Mount Contains Lead GULL WING Non-RoHS Compliant Series Voltage Reference IC 4.9mm ±0.24% -40C~85C TA 105muVrms
PDF
/
Buying Options
Total Price: USD $4.37
Unit Price: USD $4.37475
≥1 USD $4.37475
≥10 USD $3.59005
≥100 USD $3.477
≥500 USD $3.3649
≥1000 USD $3.2528
Inventory: 1170
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Noise - 10Hz to 10kHz 105μVrms
Noise - 0.1Hz to 10Hz 40μVp-p
Min Output Voltage 2.048V
Reference Type Series
Max Input Voltage 12.6V
Min Input Voltage 2.5V
Quiescent Current 35μA
Max Supply Current 35μA
Nominal Supply Current 35μA
Voltage - Input 2.5V~12.6V
Operating Supply Current 35μA
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Number of Channels 1
Max Output Current 500μA
Output Type Fixed
Output Voltage 2.048V
Number of Outputs 1
Pin Count 8
Base Part Number MAX6191
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Voltage References
Terminal Finish Matte Tin (Sn)
Temperature Coefficient 10ppm/°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Tolerance ±0.24%
Published 2010
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
