MAX6001EUR
RoHS
/
Package SOT-23
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Surface Mount GULL WING RoHS Compliant DUAL voltage reference device 2.8575mm 1.194mm 100ppm/C 12.6V
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8303
≥1 USD $0.8303
≥10 USD $0.68115
≥100 USD $0.66025
≥500 USD $0.6384
≥1000 USD $0.6175
Inventory: 1538
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 1.2955mm
Length 2.8575mm
Height Seated (Max) 1.194mm
Technical
Temp Coef of Voltage-Max 100 ppm/°C
Max Input Voltage 13.5V
Voltage - Output 1.25V
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Supply Voltage-Min (Vsup) 2.5V
Temperature Grade INDUSTRIAL
Supply Voltage-Max (Vsup) 12.6V
Max Output Current 400μA
Output Voltage 1.25V
Number of Outputs 1
Terminal Pitch 0.952mm
Supply Voltage 5V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn85Pb15)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1
Pbfree Code no
JESD-609 Code e0
Published 1999
Physical
Number of Pins 3
Package / Case SOT-23
Mount Surface Mount
