LTC2953IDD-2#PBF
RoHS
RoHS compliant
RoHS compliantPackage 12-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Power Supply Controllers, Monitors
Description
LTC2953 8542.39.00.01 Push Button On/Off Controller Tube power supply monitor 3mm 2.7V~27V 14muA -40C~85C
PDF
/
Buying Options
Total Price: USD $49.74
Unit Price: USD $49.742
≥1 USD $49.742
≥10 USD $40.8139
≥100 USD $39.539
≥500 USD $38.26315
≥1000 USD $36.9873
Inventory: 2306
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 0.8mm
Technical
Supply Current-Max (Isup) 0.026mA
Current - Supply 14μA
Adjustable Threshold YES
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Channels 1
Supply Voltage-Min (Vsup) 2.7V
Power Supplies 2.7/28V
Supply Voltage-Max (Vsup) 27V
Qualification Status Not Qualified
JESD-30 Code S-PDSO-N12
Pin Count 12
Base Part Number LTC2953
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.45mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
Voltage - Supply 2.7V~27V
Technology CMOS
Subcategory Power Management Circuits
HTS Code 8542.39.00.01
Applications Push Button, On/Off Controller
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2007
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 12-WFDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
