TPS2221PWP
RoHS
RoHS compliant
RoHS compliantPackage 14-PowerTSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tube TPS2221 Current Limiting (Fixed) Over Temperature e4 power distribution switch 5mm 3V 1A 2W
PDF
/
Buying Options
Total Price: USD $5.17
Unit Price: USD $5.1744
≥1 USD $5.1744
≥10 USD $4.64992
Inventory: 30
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mounting Type Surface Mount
Package / Case 14-PowerTSSOP (0.173, 4.40mm Width)
Surface Mount YES
Number of Pins 14
Weight 58.003124mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
JESD-609 Code e4
Feature Status Flag
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 14
ECCN Code EAR99
Resistance 72mOhm
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Power Management Circuits
Max Power Dissipation 2W
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Base Part Number TPS2221
Pin Count 14
Number of Outputs 2
Max Output Current 1A
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Number of Channels 3
Interface Parallel
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Ports 1
Nominal Supply Current 64μA
Output Configuration High Side
Power Dissipation 26.67mW
Voltage - Supply (Vcc/Vdd) Not Required
Adjustable Threshold YES
Switch Type PCMCIA Switch
Nominal Input Voltage 5.5V
Ratio - Input:Output 3:2
Voltage - Load 1.8V 3.3V 5V
Fault Protection Current Limiting (Fixed), Over Temperature
Rds On (Typ) 97m Ω
Dimensions
Height 1.2mm
Length 5mm
Width 4.4mm
Thickness 1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
