VNQ860TR-E
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tape & Reel (TR) VNQ860 Current Limiting (Fixed) Over Temperature Over Voltage e3 power distribution switch 12.8mm 36V 10mus 250mA
PDF
/
Buying Options
Total Price: USD $4.08
Unit Price: USD $4.0832
≥1 USD $4.0832
≥10 USD $3.66696
≥100 USD $3.466848
≥500 USD $3.004584
≥1000 USD $2.850531
≥3000 USD $2.557773
Inventory: 3133
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tape & Reel (TR)
Series VIPower?
JESD-609 Code e3
Feature Auto Restart, Status Flag
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
ECCN Code EAR99
Resistance 270mOhm
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Peripheral Drivers
Max Power Dissipation 16W
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 24V
Terminal Pitch 1.27mm
Base Part Number VNQ860
Pin Count 20
Number of Outputs 4
Output Type N-Channel
Max Output Current 250mA
Interface On/Off
Nominal Supply Current 70μA
Output Configuration High Side
Power Dissipation 16W
Output Current 250mA
Voltage - Supply (Vcc/Vdd) Not Required
Max Supply Current 70μA
Input Type Non-Inverting
Turn On Delay Time 10 μs
Switch Type General Purpose
Min Input Voltage 5.5V
Max Input Voltage 36V
Nominal Input Voltage 36V
Turn-Off Delay Time 40 μs
Ratio - Input:Output 1:1
Voltage - Load 5.5V~36V
Driver Number of Bits 4
Fault Protection Current Limiting (Fixed), Over Temperature, Over Voltage
Output Peak Current Limit-Nom 0.7A
Rds On (Typ) 270m Ω (Max)
Built-in Protections TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL; UNDER VOLTAGE
Dimensions
Height Seated (Max) 2.65mm
Length 12.8mm
Width 7.5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
