UC2855BDWG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description
SOIC 8542.39.00.01 BOOST Lead Free power factor correction device 35V 500kHz 25mA 2.35mm
PDF
/
Buying Options
Total Price: USD $3.95
Unit Price: USD $3.94535
≥1 USD $3.94535
≥10 USD $3.2376
≥100 USD $3.13595
≥500 USD $3.03525
≥1000 USD $2.9336
Inventory: 1170
Minimum: 1
-
+
Technical Details
Physical
Package / Case SOIC
Surface Mount YES
Number of Pins 20
Weight 569.003279mg
Technical
JESD-609 Code e4
Moisture Sensitivity Level (MSL) 2
Number of Terminations 20
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Subcategory Switching Regulator or Controllers
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 18V
Terminal Pitch 1.27mm
Frequency 500kHz
Pin Count 20
Output Voltage 7.5V
Input Voltage-Nom 18V
Temperature Grade INDUSTRIAL
Max Supply Voltage 20V
Analog IC - Other Type POWER FACTOR CONTROLLER
Max Supply Current 25mA
Input Voltage (Min) 15V
Control Mode CURRENT-MODE
Output Current-Max 1.5A
Frequency - Switching 230kHz
Input Voltage (Max) 35V
Control Technique PULSE WIDTH MODULATION
Switcher Configuration BOOST
Output Voltage-Max 7.613V
Output Voltage-Min 7.388V
Dimensions
Height 2.35mm
Length 12.8mm
Width 7.52mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
Alternative Model
