UCC28502DW
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description
GULL WING Surface Mount Obsolete ROHS3Compliant PFC IC Average Current -40C~85C 2.65mm 150muA 100kHz
PDF
/
Buying Options
Total Price: USD $4.19
Unit Price: USD $4.1888
≥1 USD $4.1888
Inventory: 2339
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
Terminal Finish NICKEL PALLADIUM GOLD
Additional Feature CAN ALSO BE PROGRAMMED FOR CURRENT MODE AND VOLTAGE MODE
Technology BICMOS
Voltage - Supply 9.7V~18V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 20
JESD-30 Code R-PDSO-G20
Input Voltage-Nom 12V
Analog IC - Other Type POWER FACTOR CONTROLLER WITH POST REGULATOR
Input Voltage (Min) 10.3V
Output Current-Max 1.2A
Frequency - Switching 100kHz
Input Voltage (Max) 15V
Control Technique PULSE WIDTH MODULATION
Switcher Configuration BOOST
Mode Average Current
Current - Startup 150μA
Dimensions
Height Seated (Max) 2.65mm
Length 12.8mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
