FAN7528MX
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description
GULL WING Surface Mount Obsolete ROHS3Compliant PFC IC Critical Conduction (CRM), Discontinuous (Transition) -40C~125C 1.75mm 40muA 12V~23V
PDF
/
Buying Options
Total Price: USD $0.47
Unit Price: USD $0.4664
≥1 USD $0.4664
Inventory: 220040
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Current - Startup 40μA
Mode Critical Conduction (CRM), Discontinuous (Transition)
Switcher Configuration BOOST
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 23V
Output Current-Max 0.4A
Input Voltage (Min) 9V
Analog IC - Other Type POWER FACTOR CONTROLLER
Input Voltage-Nom 14V
JESD-30 Code R-PDSO-G8
Pin Count 8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 12V~23V
Terminal Finish MATTE TIN
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
