TPS2113PWR
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - OR Controllers, Ideal Diodes
Description
ACTIVE (Last Updated: 1week ago) Tape & Reel (TR) Handheld/Mobile Devices e4 OR controller 1.25A 0.65mm 2.8V~5.5V 5ms
PDF
/
Buying Options
Total Price: USD $2.29
Unit Price: USD $2.288
≥1 USD $2.288
≥10 USD $2.05128
≥100 USD $1.935296
≥500 USD $1.648944
≥1000 USD $1.548307
≥3000 USD $1.35476
Inventory: 1514
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1mm
Width 4.4mm
Length 3mm
Height 1.2mm
Technical
Delay Time - OFF 5ms
Current - Output 2 1.25A
Internal Switch(s) Yes
Ratio - Input:Output 2:1
Nominal Input Voltage 5.5V
Supply Current-Max (Isup) 0.09mA
Max Input Voltage 5.5V
Number of Inputs 2
FET Type N-Channel
Min Input Voltage 2.8V
Current - Supply 55μA
Turn On Delay Time 1 ms
Adjustable Threshold YES
Output Current 1.25A
Number of Channels 2
Operating Supply Voltage 5.5V
Max Output Current 1.25A
Number of Outputs 1
Pin Count 8
Base Part Number TPS2113
Terminal Pitch 0.65mm
Supply Voltage 2.8V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.8V~5.5V
Subcategory Power Management Circuits
Applications Handheld/Mobile Devices
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Source Selector Switch
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 39.008944mg
Number of Pins 8
Surface Mount YES
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
