L6470PD
RoHS
RoHS compliant
RoHS compliantPackage 36-BSSOP (0.433, 11.00mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Motor Drivers, Controllers
Description
DMOS Tube L6470 General Purpose motor driver 45V 3A 11.1mm -40C~150C TJ
PDF
/
Buying Options
Total Price: USD $8.47
Unit Price: USD $8.4656
≥1 USD $8.4656
≥10 USD $7.64368
≥100 USD $7.288107
≥500 USD $6.328265
≥1000 USD $6.043831
≥3000 USD $5.510551
Inventory: 1496
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 36-BSSOP (0.433, 11.00mm Width) Exposed Pad
Number of Pins 36
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
Series STSPIN L64
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 36
ECCN Code EAR99
Applications General Purpose
Subcategory Motion Control Electronics
Max Power Dissipation 5W
Technology DMOS
Voltage - Supply 3.3V 5V
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 36V
Terminal Pitch 0.635mm
Base Part Number L6470
Function Driver - Fully Integrated, Control and Power Stage
Number of Outputs 1
Output Voltage 45V
Power Supplies 3.3/5V
Supply Voltage-Min (Vsup) 8V
Interface SPI
Nominal Supply Current 500μA
Output Configuration Half Bridge (4)
Power Dissipation 5W
Output Current-Max 7A
Collector Emitter Voltage (VCEO) 45V
Max Collector Current 3A
Voltage - Load 8V~45V
Max Junction Temperature (Tj) 150°C
Switching Frequency 125kHz
Motor Type Stepper
Motor Type - Stepper Bipolar
Step Resolution 1 ~ 1/128
Dimensions
Height 3.6mm
Length 16mm
Width 11.1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
