L6235PD013TR
RoHS
RoHS compliant
RoHS compliantPackage 36-BSSOP (0.433, 11.00mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Motor Drivers, Controllers
Description
DMOS Tape & Reel (TR) L6235 General Purpose motor controller 52V 2.8A 0.65mm -25C~125C TJ
PDF
/
Buying Options
Total Price: USD $8.12
Unit Price: USD $8.1224
≥1 USD $8.1224
≥10 USD $7.33832
≥100 USD $6.996704
≥500 USD $6.075168
≥1000 USD $5.802086
Inventory: 3964
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Motor Type - AC, DC Brushless DC (BLDC)
Voltage - Load 12V~52V
Current - Output 2.8A
Output Configuration Half Bridge (3)
Nominal Supply Current 6mA
Analog IC - Other Type BRUSHLESS DC MOTOR CONTROLLER
Interface Parallel
Number of Channels 3
Supply Voltage-Min (Vsup) 8V
Operating Supply Voltage 52V
Output Voltage 52V
Number of Outputs 1
Function Driver - Fully Integrated, Control and Power Stage
Base Part Number L6235
Terminal Pitch 0.65mm
Supply Voltage 48V
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 12V~52V
Technology DMOS
Subcategory Motion Control Electronics
Applications General Purpose
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 36
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series STSPIN L62
Packaging Tape & Reel (TR)
Operating Temperature -25°C~125°C TJ
Physical
Number of Pins 36
Surface Mount YES
Package / Case 36-BSSOP (0.433, 11.00mm Width) Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 12 Weeks
