IRSM836-025MA
RoHS
RoHS compliant
RoHS compliantPackage 36-PowerVQFN
Category Integrated Circuits (ICs) / PMIC - Motor Drivers, Controllers
Description
UMOS Tray IRSM836-025 Appliance motor controller 500V 2A 12mm -40C~150C TJ
PDF
/
Buying Options
Total Price: USD $5.24
Unit Price: USD $5.2448
≥1 USD $5.2448
≥10 USD $4.74144
≥100 USD $4.520736
≥500 USD $3.925187
≥1000 USD $3.88234
Inventory: 874
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 12mm
Length 12mm
Height 1mm
Technical
Motor Type - AC, DC AC, Synchronous
Switching Frequency 20kHz
Max Junction Temperature (Tj) 150°C
Isolation Voltage 1.5kV
Number of Drivers 6
Voltage - Load 400V Max
Max Collector Current 2A
Collector Emitter Voltage (VCEO) 500V
Turn-Off Delay Time 1.5 μs
Logic Function AND
Turn On Delay Time 1.5 μs
Max Supply Current 10mA
Power Dissipation 25W
Output Configuration Half Bridge (3)
Nominal Supply Current 10mA
Analog IC - Other Type AC MOTOR CONTROLLER
Interface Parallel
Max Output Current 2A
Number of Outputs 1
Function Driver - Fully Integrated, Control and Power Stage
Base Part Number IRSM836-025
Supply Voltage 15V
Terminal Position QUAD
Voltage - Supply 13.5V~16.5V
Technology UMOS
Subcategory Motion Control Electronics
Applications Appliance
Number of Terminations 36
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Published 2013
Packaging Tray
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 36
Package / Case 36-PowerVQFN
Mounting Type Surface Mount
Mount PCB, Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
