UDQ2916LBTR-T
RoHS
RoHS compliant
RoHS compliantPackage 24-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Motor Drivers, Controllers
Description
Tape & Reel (TR) UDQ2916 ALSO REQUIRES 10V TO 45V VBB SUPPLY General Purpose motor driver 5V 750mA 7.5mm -40C~150C TJ
PDF
/
Buying Options
Total Price: USD $6.36
Unit Price: USD $6.3593
≥1 USD $6.3593
≥10 USD $5.21835
≥100 USD $5.05495
≥500 USD $4.8925
≥1000 USD $4.7291
Inventory: 1112
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-SOIC (0.295, 7.50mm Width)
Number of Pins 24
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tape & Reel (TR)
Published 2006
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 24
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Additional Feature ALSO REQUIRES 10V TO 45V VBB SUPPLY
HTS Code 8542.39.00.01
Subcategory Motion Control Electronics
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 5V
Terminal Pitch 1.27mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number UDQ2916
Function Driver - Fully Integrated, Control and Power Stage
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.25V
Power Supplies 5V
Supply Voltage-Min (Vsup) 4.75V
Interface Parallel
Analog IC - Other Type STEPPER MOTOR CONTROLLER
Output Configuration Half Bridge (4)
Current - Output 750mA
Supply Current-Max (Isup) 50mA
Voltage - Load 10V~45V
Motor Type - AC, DC Brushed DC
Motor Type - Stepper Bipolar
Dimensions
Height Seated (Max) 2.65mm
Length 15.4mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
