MAX8759ETI+
RoHS
RoHS compliant
RoHS compliantPackage 28-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Lighting, Ballast Controllers
Description
IC CNTRL CCFL BACKLIGHT 28TQFN
PDF
/
Buying Options
Total Price: USD $4.26
Unit Price: USD $4.2617
≥1 USD $4.2617
≥10 USD $3.49695
≥100 USD $3.3877
≥500 USD $3.27845
≥1000 USD $3.1692
Inventory: 5004
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.8mm
Technical
Dimming Yes
Switcher Configuration PUSH-PULL
Resolution 1 B
Control Technique PULSE WIDTH MODULATION
Control Mode CURRENT-MODE
Input Voltage (Min) 4.5V
Nominal Supply Current 6μA
Operating Supply Current 2.5mA
Input Voltage-Nom 12V
Operating Supply Voltage 28V
Max Output Current 1mA
Qualification Status Not Qualified
Pin Count 28
Base Part Number MAX8759
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 30kHz~80kHz
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 4.5V~28V
Technology BICMOS
Max Power Dissipation 1.702W
Subcategory Switching Regulator or Controllers
HTS Code 8542.31.00.01
Additional Feature RESONANT MODE ALSO AVAILABLE
Terminal Finish Matte Tin (Sn)
Type CCFL Controller
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2012
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 28
Surface Mount YES
Package / Case 28-WFQFN Exposed Pad
Mounting Type Surface Mount
