CAT4003BSD-GT3
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Lead Free RoHS Compliant GULL WING DUAL led driver 85C 2.4V 2mm
PDF
/
Buying Options
Total Price: USD $2.57
Unit Price: USD $2.5696
≥1 USD $2.5696
Inventory: 25479
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status CONSULT SALES OFFICE (Last Updated: 2 days ago)
Physical
Surface Mount YES
Number of Pins 6
Technical
JESD-609 Code e4
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.39.00.01
Subcategory Display Drivers
Terminal Position DUAL
Multiplexed Display Capability NO
Number of Segments 3
Interface IC Type LED DISPLAY DRIVER
Halogen Free Halogen Free
Supply Voltage-Min (Vsup) 2.4V
Temperature Grade INDUSTRIAL
Power Supplies 3/5V
Supply Voltage-Max (Vsup) 5.5V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Pin Count 6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 4V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 1.25mm
Length 2mm
Height Seated (Max) 1.1mm
