TPS2321IDRG4
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Hot Swap Controllers
Description
DUAL EAR99 TPS2321 Circuit Breaker Fault Timeout Slew Rate hot swap controller 9.9mm 500muA 3V~13V 3V~5.5V -40C~85C
PDF
/
Buying Options
Total Price: USD $19.05
Unit Price: USD $19.049621
≥1 USD $19.049621
≥10 USD $17.971341
≥100 USD $16.954092
≥500 USD $15.994432
≥1000 USD $15.08908
Inventory: 1230
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Weight 141.690917mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Feature Latched Fault, UVLO
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Type Hot Swap Controller
Applications General Purpose
Subcategory Power Management Circuits
Voltage - Supply 3V~13V 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 4.5V
Base Part Number TPS2321
Pin Count 16
Output Voltage 21V
Supply Voltage-Min (Vsup) 3V
Number of Channels 2
Nominal Supply Current 200μA
Adjustable Threshold YES
Current - Supply 500μA
Nominal Input Voltage 13V
Internal Switch(s) No
Programmable Features Circuit Breaker, Fault Timeout, Slew Rate
Feature Pins DISCH1, DISCH2, ENABLE, /FAULT, ISET1, ISET2, TIMER, VREG
Dimensions
Height Seated (Max) 1.75mm
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
