IPS042G
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / PMIC - Hot Swap Controllers
Description
Tin/Lead (Sn/Pb) EAR99 On/Off OVER CURRENT; THERMAL hot swap controller 4.9mm 530mA 500mOhm 6V
PDF
/
Buying Options
Total Price: USD $1.88
Unit Price: USD $1.88005
≥1 USD $1.88005
≥10 USD $1.5428
≥100 USD $1.49435
≥500 USD $1.4459
≥1000 USD $1.39745
Inventory: 10542
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case SOIC
Number of Pins 8
Technical
Packaging Bulk
Published 2001
JESD-609 Code e0
Pbfree Code no
Moisture Sensitivity Level (MSL) 1
Number of Terminations 8
ECCN Code EAR99
Resistance 370mOhm
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Subcategory Peripheral Drivers
Technology MOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 2
Supply Voltage 14V
Current Rating 530mA
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 8
Max Output Current 530mA
Operating Supply Voltage 35V
Temperature Grade AUTOMOTIVE
Number of Channels 2
Interface On/Off
Max Supply Voltage 6V
Min Supply Voltage 4V
Power Dissipation-Max 1W
Nominal Supply Current 10mA
Output Configuration Low Side
Power Dissipation 1W
Current - Output 530mA
Output Current per Channel 530mA
Rise Time 1.3μs
Fall Time (Typ) 1.5 μs
Driver Number of Bits 2
Fault Protection Over Temperature
Turn On Time 0.5 μs
Output Peak Current Limit-Nom 1.1A
Drain to Source Resistance 500mOhm
Built-in Protections OVER CURRENT; THERMAL
Output Current Flow Direction SINK
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
Alternative Model
