L6747C
RoHS
RoHS compliant
RoHS compliantPackage 8-VFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tray L6747 Half-Bridge Non-Inverting gate driver 45ns 0C~125C TJ 3.5A - 2.25W
PDF
/
Buying Options
Total Price: USD $0.79
Unit Price: USD $0.78755
≥1 USD $0.78755
≥10 USD $0.64695
≥100 USD $0.62605
≥500 USD $0.6061
≥1000 USD $0.58615
Inventory: 1845
Minimum: 1
-
+
Technical Details
Technical
Qualification Status Not Qualified
Max Output Current 3.5A
Power Dissipation 2.25W
Propagation Delay 45 ns
Input Type Non-Inverting
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Channel Type Synchronous
Number of Drivers 2
Driven Configuration Half-Bridge
Gate Type N-Channel MOSFET
Current - Peak Output (Source, Sink) 3.5A -
Logic Voltage - VIL, VIH 0.8V 2V
High Side Voltage - Max (Bootstrap) 41V
Base Part Number L6747
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 12V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position DUAL
Voltage - Supply 5V~12V
Subcategory MOSFET Drivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Discontinued
JESD-609 Code e4
Packaging Tray
Operating Temperature 0°C~125°C TJ
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 8
Package / Case 8-VFDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
