FAN7361M
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube High-Side TRANSIENT; UNDER VOLTAGE Non-Inverting gate driver 70ns 30ns -40C~150C TJ 250mA 500mA 1V 3.6V
PDF
/
Buying Options
Total Price: USD $2.77
Unit Price: USD $2.76545
≥1 USD $2.76545
≥10 USD $2.26955
≥100 USD $2.1983
≥500 USD $2.12705
≥1000 USD $2.05675
Inventory: 1229
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Output Current Flow Direction SOURCE SINK
High Side Voltage - Max (Bootstrap) 600V
Built-in Protections TRANSIENT; UNDER VOLTAGE
Logic Voltage - VIL, VIH 1V 3.6V
Current - Peak Output (Source, Sink) 250mA 500mA
Gate Type IGBT, N-Channel MOSFET
Driven Configuration High-Side
Turn On Time 0.2 μs
Number of Drivers 1
Channel Type Single
Interface IC Type BUFFER OR INVERTER BASED PERIPHERAL DRIVER
Rise / Fall Time (Typ) 70ns 30ns
Input Type Non-Inverting
Qualification Status COMMERCIAL
JESD-30 Code R-PDSO-G8
Pin Count 8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 10V~20V
Terminal Finish MATTE TIN
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Alternative Model
