NCP1392BDR2G

ON Semiconductor
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description Tape & Reel (TR) NCP1392 Half-Bridge 2008 gate driver 40ns -40C~125C TJ 500mA 1A 600V
PDF
/
Buying Options
Total Price: USD $6.64
Unit Price: USD $6.6367
≥1 USD $6.6367
≥10 USD $5.4454
≥100 USD $5.27535
≥500 USD $5.1053
≥1000 USD $4.9343
≥3000 USD $4.42415
Inventory: 14004
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8

Technical

Operating Temperature -40°C~125°C TJ
Packaging Tape & Reel (TR)
Published 2008
JESD-609 Code e3
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Tin (Sn)
Subcategory MOSFET Drivers
Voltage - Supply 8V~20V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 12V
Frequency 250kHz
Base Part Number NCP1392
Pin Count 8
Max Output Current 1A
Output Current 500mA
Propagation Delay 500 ns
Input Type Non-Inverting
Turn On Delay Time 500 ns
Halogen Free Halogen Free
Rise Time 40ns
Fall Time (Typ) 20 ns
Rise / Fall Time (Typ) 40ns 20ns
Channel Type Synchronous
Number of Drivers 2
Output Peak Current Limit-Nom 1A
Driven Configuration Half-Bridge
Gate Type N-Channel MOSFET
Current - Peak Output (Source, Sink) 500mA 1A
High Side Driver YES
High Side Voltage - Max (Bootstrap) 600V

Dimensions

Height 1.5mm
Length 5mm
Width 4mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
