TC4426VMF
RoHS
RoHS compliant
RoHS compliantPackage 8-VDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube TC4426 Low-Side 2004 gate driver 30ns -40C~150C TJ 1.5A 1.5A 0.8V 2.4V
PDF
/
Buying Options
Total Price: USD $0.97
Unit Price: USD $0.967343
≥1 USD $0.967343
≥10 USD $0.912581
≥100 USD $0.860931
≥500 USD $0.812203
≥1000 USD $0.766227
Inventory: 8613
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-VDFN Exposed Pad
Number of Pins 8
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
Published 2004
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory MOSFET Drivers
Technology CMOS
Voltage - Supply 4.5V~18V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number TC4426
Pin Count 8
Max Output Current 1.5A
Nominal Supply Current 4.5mA
Max Supply Current 4.5mA
Propagation Delay 50 ns
Input Type Inverting
Turn On Delay Time 50 ns
Rise Time 30ns
Fall Time (Typ) 30 ns
Rise / Fall Time (Typ) 19ns 19ns
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Channel Type Independent
Number of Drivers 2
Turn On Time 0.04 μs
Output Peak Current Limit-Nom 1.5A
Driven Configuration Low-Side
Gate Type N-Channel, P-Channel MOSFET
Current - Peak Output (Source, Sink) 1.5A 1.5A
High Side Driver YES
Logic Voltage - VIL, VIH 0.8V 2.4V
Turn Off Time 0.06 μs
Dimensions
Height Seated (Max) 0.95mm
Length 6mm
Width 5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
