MIC4425YN
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube MIC4425 Low-Side 2005 gate driver 23ns -40C~150C TJ 3A 3A 960mW
PDF
/
Buying Options
Total Price: USD $2.27
Unit Price: USD $2.2704
≥1 USD $2.2704
≥10 USD $1.8832
≥100 USD $1.7072
Inventory: 324
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Number of Pins 8
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
Published 2005
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Power Dissipation 960mW
Technology BCDMOS
Voltage - Supply 4.5V~18V
Terminal Position DUAL
Number of Functions 2
Base Part Number MIC4425
Number of Outputs 2
Output Voltage 25mV
Max Output Current 3A
Nominal Supply Current 2mA
Output Current 3A
Propagation Delay 75 ns
Input Type Inverting, Non-Inverting
Turn On Delay Time 33 ns
Rise Time 23ns
Fall Time (Typ) 35 ns
Turn-Off Delay Time 33 ns
Rise / Fall Time (Typ) 28ns 32ns
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Channel Type Independent
Turn On Time 0.1 μs
Output Peak Current Limit-Nom 3A
Driven Configuration Low-Side
Gate Type N-Channel, P-Channel MOSFET
Current - Peak Output (Source, Sink) 3A 3A
High Side Driver NO
Logic Voltage - VIL, VIH 0.8V 2.4V
Turn Off Time 0.1 μs
Dimensions
Height 3.43mm
Length 9.65mm
Width 6.48mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
