MIC4424ZWM
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube MIC4424 Low-Side 2005 gate driver 28ns 70C 3A 3A 0.8V 2.4V
PDF
/
Buying Options
Total Price: USD $1.12
Unit Price: USD $1.1176
≥1 USD $1.1176
Inventory: 2608
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Number of Pins 16
Supplier Device Package 16-SOIC
Technical
Operating Temperature 0°C~150°C TJ
Packaging Tube
Published 2005
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Voltage - Supply 4.5V~18V
Base Part Number MIC4424
Number of Outputs 2
Max Output Current 3A
Max Supply Voltage 18V
Min Supply Voltage 4.5V
Nominal Supply Current 2mA
Output Current 3A
Propagation Delay 75 ns
Input Type Non-Inverting
Turn On Delay Time 75 ns
Rise Time 28ns
Fall Time (Typ) 32 ns
Rise / Fall Time (Typ) 28ns 32ns
Channel Type Independent
Number of Drivers 2
Driven Configuration Low-Side
Gate Type N-Channel, P-Channel MOSFET
Current - Peak Output (Source, Sink) 3A 3A
Logic Voltage - VIL, VIH 0.8V 2.4V
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
