AUIRS2117STR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tape & Reel (TR) AUIRS2117S High-Side 2000 gate driver 130ns -40C~150C TJ 290mA 600mA 625mW
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
Inventory: 29713
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tape & Reel (TR)
Published 2000
Series Automotive, AEC-Q100
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Peripheral Drivers
Max Power Dissipation 625mW
Voltage - Supply 10V~20V
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 15V
Base Part Number AUIRS2117S
Max Output Current 600mA
Power Dissipation 625mW
Output Current 290mA
Propagation Delay 225 ns
Input Type Non-Inverting
Turn On Delay Time 140 ns
Rise Time 130ns
Fall Time (Typ) 65 ns
Turn-Off Delay Time 140 ns
Rise / Fall Time (Typ) 75ns 25ns
Channel Type Single
Number of Drivers 1
Driven Configuration High-Side
Gate Type IGBT, N-Channel MOSFET
Current - Peak Output (Source, Sink) 290mA 600mA
Logic Voltage - VIL, VIH 6V 9.5V
High Side Voltage - Max (Bootstrap) 600V
Dimensions
Height 1.4986mm
Length 4.9784mm
Width 3.9878mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
