VNH7013XP-E

STMicroelectronics
RoHS
RoHS RoHS compliant
Package 36-PowerBFSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Full, Half-Bridge Drivers
Description IC MOTOR DRIVER PAR 36POWERSSO
PDF
/
Inventory: 1624
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Technical

Load Type Inductive
Rds On (Typ) 7.3m Ω LS, 5.7m Ω HS
Fault Protection Over Temperature
Current - Output / Channel 40A
Output Configuration Half Bridge (2)
Interface Logic
Base Part Number VNH7013
Voltage - Supply 72V Max
Technology Power MOSFET
Applications DC Motors, General Purpose
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series VIPower?
Packaging Tube
Operating Temperature -40°C~175°C TJ

Physical

Number of Pins 36
Package / Case 36-PowerBFSOP (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status NRND (Last Updated: 8 months ago)
Factory Lead Time 20 Weeks
