ATA6836C-TIQW
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Full, Half-Bridge Drivers
Description
Open Load Detect Over Temperature Short Circuit UVLO OVER CURRENT; THERMAL; TRANSIENT Lead Free Tape & Reel (TR) bridge driver 650mA 5V 1Ohm LS 1Ohm HS 2.7mm
PDF
/
Buying Options
Total Price: USD $2.95
Unit Price: USD $2.95355
≥1 USD $2.95355
≥10 USD $2.42345
≥100 USD $2.34745
≥500 USD $2.2724
≥1000 USD $2.1964
Inventory: 63376
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Length 17.9mm
Height Seated (Max) 2.7mm
Technical
Load Type Inductive, Capacitive, Resistive
Built-in Protections OVER CURRENT; THERMAL; TRANSIENT
Rds On (Typ) 1 Ω LS, 1 Ω HS
Fault Protection Open Load Detect, Over Temperature, Short Circuit, UVLO
Voltage - Load 5.5V~40V
Logic Function AND
Max Supply Current 150μA
Output Current 650mA
Output Configuration Half Bridge (6)
Interface SPI
Max Output Current 650mA
Number of Outputs 6
Base Part Number ATA6836C
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology Power MOSFET
Applications Bulbs, DC Motors, Resistors
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Feature Status Flag
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 28
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
