Package 40-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / PMIC - Display Drivers
Description A/D 3.5Digits Tube TC7117 Tin/Lead (Sn/Pb) display driver 1.8mA 5V 2.54mm 0C~70C
PDF
/
Inventory: 2778
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case 40-DIP (0.600, 15.24mm)
Number of Pins 40

Technical

Operating Temperature 0°C~70°C
Packaging Tube
Published 2006
JESD-609 Code e0
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 40
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Analog to Digital Converters
Technology CMOS
Terminal Position DUAL
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 2.54mm
Base Part Number TC7117
Pin Count 40
Output Voltage 700mV
Operating Supply Voltage 5V
Number of Elements 1
Polarity Unipolar
Configuration 7 Segment
Operating Supply Current 800μA
Power Dissipation 1.23W
Max Supply Current 1.8mA
Number of Bits 13
Converter Type ADC, DUAL-SLOPE
Number of Analog In Channels 1
Output Bit Code BINARY
Display Type LED
Dual Supply Voltage 5V
Number of LEDs 7
Analog Input Voltage-Max 2V
Negative Supply Voltage-Nom -5V
Number of Segments 24
Analog Input Voltage-Min 0.2V
Digits or Characters A/D 3.5 Digits
