MAX6783TEB+
RoHS
RoHS compliant
RoHS compliantPackage 16-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description
Lead Free ROHS3Compliant Battery Monitor Obsolete IC Battery Monitor 1.667W -40C~85C TA 3mm 5.5V
PDF
/
Buying Options
Total Price: USD $4.48
Unit Price: USD $4.476508
≥1 USD $4.476508
≥10 USD $4.223116
≥100 USD $3.984075
≥500 USD $3.758557
≥1000 USD $3.54581
Inventory: 1193
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 0.8mm
Technical
Number of Cells 4
Battery Chemistry Multi-Chemistry
Fault Protection Reverse Battery
Watchdog Timer No
Adjustable Threshold NO
Max Supply Current 10μA
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Min Supply Voltage 1.2V
Max Supply Voltage 5.5V
Number of Channels 4
Power Supplies 1.8/5V
Function Battery Monitor
Base Part Number MAX6783
Terminal Pitch 0.5mm
Supply Voltage 1.6V
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology BICMOS
Max Power Dissipation 1.667W
Subcategory Power Management Circuits
Terminal Finish TIN
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2010
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 16
Package / Case 16-WFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
