LTC4123EDC
RoHS
/
Package 6-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Battery Chargers
Description
S-PDSO-N6 LTC4123 Matte Tin (Sn) Tube battery charger 1.5075V 25mA 0.5mm -20C~85C TA
PDF
/
Buying Options
Total Price: USD $5.08
Unit Price: USD $5.076412
≥1 USD $5.076412
≥200 USD $1.964969
≥500 USD $1.964969
≥1000 USD $1.862077
Inventory: 1262
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 2mm
Length 2mm
Height Seated (Max) 0.8mm
Technical
Battery Pack Voltage 1.5075V
Charge Current - Max 25mA
Current - Charging Constant - Programmable
Voltage - Supply (Max) 5V
Number of Cells 1
Battery Chemistry Nickel Metal Hydride
Fault Protection Over Voltage
Supply Current-Max (Isup) 0.2mA
Analog IC - Other Type BATTERY CHARGE CONTROLLER
JESD-30 Code S-PDSO-N6
Pin Count 6
Base Part Number LTC4123
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position DUAL
Technology CMOS
Additional Feature SEATED HT-CALCULATED
Terminal Finish Matte Tin (Sn)
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Operating Temperature -20°C~85°C TA
Physical
Surface Mount YES
Package / Case 6-WFDFN Exposed Pad
Mounting Type Surface Mount
