0470804002

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Pluggable Connectors
Description Conn SATA PL 7 POS 1.27mm Solder RA SMD 7 Terminal 1 Port Embossed T/R
PDF
/
Buying Options
Total Price: USD $1.47
Unit Price: USD $1.4696
≥1 USD $1.4696
≥10 USD $1.25312
≥100 USD $1.03488
Inventory: 2774
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness 30.0μin 0.76μm

Technical

Connector Style Plug
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender MALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Total Number of Contacts 7
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Positions 7
Connector Type SATA
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide
Series 47080
Packaging Tape & Reel (TR)

Physical

Mounting Type Surface Mount, Right Angle
Contact Material NOT SPECIFIED

Supply Chain

Factory Lead Time 16 Weeks
