DSA2311KL1-R0009TVAO
RoHS
RoHS compliant
RoHS compliantPackage 6-VDFN
Category Crystals, Oscillators, Resonators / Pin Configurable/Selectable Oscillators
Description
ROHS3Compliant Enable/Disable DUAL MEMS oscillating selection -40C~105C 2.25V~3.6V 23mA 0.098Lx0.079W 2.50mmx2.00mm
PDF
/
Inventory: 6369
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 6-VDFN
Surface Mount YES
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Series DSA2311
Size / Dimension 0.098Lx0.079W 2.50mmx2.00mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Type XO (Standard)
Terminal Finish Matte Tin (Sn)
Voltage - Supply 2.25V~3.6V
Terminal Position DUAL
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Terminal Pitch 0.825mm
Time@Peak Reflow Temperature-Max (s) 40
Frequency Stability ±50ppm
Output LVCMOS
JESD-30 Code R-PDSO-N6
Function Enable/Disable
Base Resonator MEMS
Current - Supply (Max) 23mA
Frequency - Output 1 25MHz
Dimensions
Height 0.035 0.90mm
Length 2.5mm
Width 2mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q100
