DSC1101DM1-033.3333T

Microchip Technology
RoHS
RoHS RoHS compliant
Package 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description MEMS OSC XO 33.3333MHZ CMOS SMD
PDF
/
Inventory: 3717
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 0.035 0.90mm
Height 889μm

Technical

Max Supply Current 35mA
Current - Supply (Disable) (Max) 95μA
Symmetry-Max 55/45%
Fall Time-Max 2ns
Rise Time-Max 2ns
Operating Frequency 33.3333MHz
Physical Dimension 2.5mm x 2.0mm x 0.85mm
Base Resonator MEMS
Function Standby (Power Down)
Output CMOS
Frequency Stability ±50ppm
Frequency 33.3333MHz
Voltage - Supply 2.25V~3.6V
Additional Feature STANDBY; ENABLE/DISABLE FUNCTION; TR
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type XO (Standard)
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e4
Size / Dimension 0.098Lx0.079W 2.50mmx2.00mm
Series DSC1101
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C

Physical

Package / Case 6-SMD, No Lead
Mounting Type Surface Mount
Mount Surface Mount
