TLP2398(E
RoHS
/
Package 6-SOIC (0.179, 4.55mm Width), 5 Leads
Category Isolators / Optoisolators - Logic Output
Description
6-SOIC (0.179 4.55mm Width) 5Leads 1 1/0 DC Logic Output Optoisolator 20kV/mus 3750Vrms 5Mbps 20mA
PDF
/
Inventory: 6381
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Inputs - Side 1/Side 2 1/0
Common Mode Transient Immunity (Min) 20kV/μs
Propagation Delay tpLH / tpHL (Max) 250ns, 250ns
Current - DC Forward (If) (Max) 20mA
Current - Output / Channel 25mA
Rise / Fall Time (Typ) 15ns 12ns
Data Rate 5Mbps
Optoelectronic Device Type LOGIC IC OUTPUT OPTOCOUPLER
Input Type DC
Voltage - Forward (Vf) (Typ) 1.5V
Number of Channels 1
Output Type Push-Pull, Totem Pole
Voltage - Isolation 3750Vrms
Voltage - Supply 3V~20V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Package / Case 6-SOIC (0.179, 4.55mm Width), 5 Leads
Mounting Type Surface Mount
